Brief description:
1.3PCS 60W RGBW LED
2.4860Lumens output
3.Third generation optical desgin to mix SMS & TIR technology zooming
4.Wide zoom range,qualified for all stages rendering and rental service
size: 351*189*349mm
weight: 11.3KG
Power input | AC 100-240V 47-63Hz, PF>0.9 |
Output | DC24V, longevity 15000Hours |
Rated Power | 180W(171@220V 50Hz) |
Luminaire Efficiency | >0.8, Light Effiacy >28.5lm/WLED |
LED Lumens | 3PCS 60W RGBW LED, 4A driving, Full on Typ 4860Lumens(40Deg) |
LED Color | R=625nm,G=525nm,B=460nm,W=6500K,good Color mixing,Standard Deveation of Chromaticity<0.005 |
Light Beam(10%) | 8~56°mechanical zoomable, light beam shape between hexagon and round |
Typical Intensity | 9°(67695.2Cd), 89°(3384.7Cd)also beam between |
Control signal | Meet E1.11 - 2004 USITT DMX512-A,Compatible with W-DMX and LM-DMXA1 |
DMX Channel | Standard 9CH, HSI and other optional on menu |
Zoom Moto | Designed with SMS technology and concaved lens, mechanical Linear zoom |
Strobe ability | could be 0-20 F.P.S with asynchronous stroboscopic effect |
Dimming Curve | with linear dimming curves, PWM>1500Hz, video flicker free |
Display | LCD turn off back light after 2 minutes no operation |
Housing material | ABS and QR235, standard Matte balck, with install bracket and fastdo screw |
Heat sink | neutrally and Light board is protected not higher than 65ºC |
Housing material | ABS and QR235, standard Matte balck, with install bracket and fastdo screw |
Soldering technology | 180ºCReflow Soldering, 15000 hours Longevity for MCU mainboard, Moto board |
Conectors | Same Powercon Yellow/Black soucket, 3XLR/5XLR IP Rated base |
Handle | 3 M11 holes center distance 70mm |
Safty | Class II, Endure 5ms 1.5KV shock, Insulated Resistance>2MΩ Flame Rating V-1, Protect Rated IP65 |
Cerficated | Product pass CE, Rohs, SMPS pass CQC or UL60950, UL8750 |
Weight | 11.3KG |
size | 351*189*349mm |
Operating temperature | -20~+45ºC |
