Pointy 700 ZOOM -LED wash

Brief description：
1.37×15W RGBW Multichip LEDs: Delivers 9,000+ lumens (30% brighter than competitors) with vibrant color transitions from pastels to deep saturation, plus 237 virtual colors and 5 white presets (2,700K–8,000K).

2.8°–63° Motorized Zoom: Patented 8:1 high-efficiency optics for seamless switching between tight beams and expansive washes, ideal for aerial effects or full-stage coverage.
3. 3Independent LED Rings: Unique pixel control for dynamic effects

Inquiry

Pictures and video Specification Photometric User's document

moving head light led wash light zoom, moving head led light, zoom moving led light,

V. Technical parameters:

Voltage: AC100~240V 50/60HZ
Power: 37*15W
Lamp beads: 37 four-in-one LED lamp beads
Control mode: DMX512, self-propelled, master-slave, voice control, RDM function and ROBE channel.
Channels: CH37A, CH21, CH15, CH10, CH37B, CH18, CH25 and CH46.
Dimming: 32bit 0~100% linear dimming
Features: shaking head+dyeing+focusing.
Working temperature: -30 ~50℃
Strobe frequency: 1~30HZ
Appearance: metal, black
Connection mode: DMX512 input/output/power input/output.
IP grade: IP20

Voltage: AC 100–240V, 50/60Hz
Power Consumption: Max. 415W @230V/50Hz
Light Source: 37 × 15W RGBW LED multichips (4-in-1)
Total Lumen Output: 9, 000+ lumens
Light Intensity: 9, 780 lx @5m
Zoom Range: 8°–63° | High-efficiency optical system (8:1 ratio)
Effects: LED wash, 3-pixel ring control, rainbow, tungsten emulation, preset whites.
Virtual Color Wheel: 237 colors including whites (2, 700K–8, 000K)
Control Modes: DMX512, standalone, master/slave, sound-activated, RDM, Robe channel compatibility.
Channels: 37A, 21, 15, 10, 37B, 18, 25, 46
Dimming: 32-bit linear 0–100%
Features: Pan/tilt, color mixing, focus adjustment
Pan/Tilt: 450° horizontal / 300° vertical
Operating Temp: -30°C to +50°C (-22°F to 122°F)
Strobe: 1–30Hz
Housing: Metal + plastic | Standard color: black (custom colors available)
Connections: DMX512 In/Out, power In/Out.
IP Rating: IP20

Longman Pointy 700 ZOOM: Redefine Stage Lighting with Unmatched Versatility and Precision
Transform stages, concerts, and events into immersive visual spectacles with the Longman Pointy 700 ZOOM—a groundbreaking moving head LED wash light that merges razor-sharp beams, dynamic color control, and unparalleled adaptability. Designed for professionals who demand innovation, this fixture redefines what a zoom moving LED light can achieve, whether illuminating indoor theaters or open-air festivals.

Unmatched Brightness and Color Brilliance

37 × 15W RGBW Multichip LEDs: Deliver 9, 000+ lumens of vibrant, saturated light—30% brighter than conventional fixtures—with seamless transitions from soft pastels to deep, rich hues.
3 Concentric LED Rings: Independently control each ring for mesmerizing effects like color waves, ring-specific strobes (patent pending), or synchronized patterns.
Virtual Color Wheel: 237 colors + 5 pre-programmed whites (2, 700K–8, 000K) for flawless tungsten emulation or pure white washes.

Precision Optics and Hybrid Functionality

8°–63° Motorized Zoom: Cover stages with pinpoint accuracy or expansive washes using Longman’s patented 8:1 high-efficiency optical system.
Dual-Mode Mastery: Switch effortlessly between beam, wash, and FX modes—ideal for aerial patterns, audience blinders, or even venue-wide illumination.
32-Bit Dimming: Ultra-smooth 0–100% transitions for cinematic fades or dramatic reveals.

Dynamic Control and Durability

450° Pan / 300° Tilt: Silent, rapid movement with 16-bit precision for seamless repositioning.
8 DMX Channel Modes: Including compatibility with RDM and Robe protocols for seamless integration into professional setups.
Extreme Environment Ready: Operates in -30°C to +50°C (-22°F to 122°F) with a rugged metal/plastic housing (IP20).

Standout Features for Creative Freedom

Pixel Ring Effects: Strobe individual LED rings at 1–30Hz for pulsating crowd energizers or rhythmic accents.
Rainbow & Tungsten Effects: Instantly match ambient lighting or create mood shifts with preset color temperatures.
Compact & Slim Design: Fits seamlessly into tight rigs while maximizing output for tours or permanent installations.

Why Choose the Pointy 700 ZOOM?

Multi-Purpose Powerhouse: Perfect for concerts, theaters, weddings, or architectural lighting—adapt to any scenario.
Energy-Efficient Performance: 415W max consumption outperforms traditional 1, 000W fixtures.
Plug-and-Play Versatility: DMX512, sound activation, or standalone modes for effortless control.

Technical Excellence

Light Intensity: 9, 780 lx @5m | Zoom Ratio: 8:1
Weight & Build: Durable yet lightweight for truss, floor, or wall mounting.
Included: DMX/power cables | Custom Colors: Available on request.

Perfect For:

Concerts & Festivals: Sync color waves to live music or blind crowds with strobes.
Theaters & Events: Create atmospheric washes or dramatic beam accents.
Nightclubs & DJ Sets: Energize dance floors with dynamic ring effects.

Elevate Your Lighting Game
The Pointy 700 ZOOM isn’t just a light—it’s a creative tool that empowers designers to push boundaries. Whether projecting across stadiums or framing intimate stages, it delivers the precision of a moving head LED light and the flexibility of a zoom moving LED light in one sleek package.
Ready to Illuminate Like Never Before?
Explore More: Visit Longman’s website to discover how the Pointy 700 ZOOM can transform your productions.
