Red: 635nm / 14W；Green: 520nm / 24W；Blue: 445nm / 24W
Scanning Speed: 50K
Input Voltage: AC 90–245V, 50–60Hz
Total Power: 1000W
Laser Beam Parameters: Beam diameter at outlet aperture ＜ 3 mm, divergence angle ＜ 1.5 mrad
Laser Safety: Overload Protection
Laser Source Lifespan: Over 20, 000 hours
Scanning Speed: 50Kpps
Scanning Angle: 60°
DMX Channels: 27 Channels
Dimming: 0–100% linear dimming
Control Modes: DMX / ILDA PC Control / Automatic
Basic Patterns: 200 pieces (3000 extended patterns, 255 animations)
Horizontal Rotation: Stepless Rotation (available angles: 540°, 630°, 900°, 1800°, etc.)
Vertical Rotation: Stepless Rotation (available angles: 270°, 180°, 540°, 1080°, etc.)
Ingress Protection Rating: IP65
Fanless design with heat dissipation via aluminum housing; equipped with new-type light source driver for low heat generation.
Applications: Cultural tourism landscape projects, outdoor landmark lighting, water screen & movable screen projection, large-scale performances
Fixture Dimensions: L 40.2 × W 60.1 × H 75.5 cm
Fixture Net Weight: 60.3 kg
Flight Case Dimensions: L 64.5 × W 45 × H 97 cm
Flight Case Weight: 22 kg
Gross Weight: 82.3 kg
