Pixel Pitch: 3.91 × 7.82 mm (H × V)
Pixel Density: 16, 384 dots/㎡
LED Lamp: SMD 1921
Module Size: 500 (W) × 125 (H) mm
Module Resolution: 128 (W) × 16 (H)
Cabinet Resolution: 256 (W) × 128 (H)
Cabinet Size: 1000 (W) × 500 (H) mm
Cabinet Material: Aluminum profile, light transmittance 41%
Screen Brightness: 4500–5000 cd/㎡
Viewing Angle: 160° (horizontal), 160° (vertical)
Minimum Viewing Distance: 3.9 m
Grayscale: 14 bit
Max Power Consumption: 700 W/㎡
Average Power Consumption: 250 W/㎡
Operating Voltage: AC 100–240 V
Frame Rate: 60 Hz
Refresh Rate: 3840 Hz / 7680 Hz
Operating System: Win7 & XP
Control Method: Computer / Processor
Operating Temperature: −40℃ to +60℃
IP Rating (Front/Rear): IP65 / IP65
Installation/Maintenance: Rear installation / Rear maintenance
Lifespan: 100, 000 hours
