| Voltage input | AC 90-240V 47-63Hz,PF>0.9 |
| Volatage Output | 24V,SMPS longevity 15000Hours |
| Rated Power | 90W(@220V 50Hz) |
| Luminaire Efficiency | >0.9,Light Effiacy >660mW/W |
| LED Lumens | 36pcs*3W Helio UV LED, total 27W Radiometric Power,about 11Lumens |
| LED Wavelength | 380-405nm |
| Field Angle(10%) | standard 30 °,8°,15°,45°,60°,60*1°Etc optional |
| PWM frequency | >1500Hz,video flicker free |
| Control signal | DMX512,32 bit Dim 4 square law dimming, smooth in low DMX Value dimming, not Jumping, no vision shock |
| Control mode | DMX1990/DMX512A/stand alone/master and slave |
| Chanel option | 3CH,Dimmer,Strobe and Dimming Curve |
| Housing material | Die cast aluminum ADC12,standard Matte balck, customized glossy White painting |
| Safty | Class II, 3C 2.5mm2 VDE cable, Flame Rating V-1, Protect Rated IP65 |
| Operate temperature | -20~+45℃,Light board peak temperature 80℃ |
| Cerficated | CE, Rohs, CQC,UL |
| Weight | 4.7Kg,with double yokes 3mm thick supporting bracket |
| Size | 30*32*39CM |
 |
