Brief description：
1.36pcs*1W RGB LED
2.1652 Lumens output
3.Dim 4 Square law dimming for 0-100%
4.hight effieciency light output 90% Lumens within 10% Intensity field angle
Size and Weight: 996*57*100mm/2KG
| Light source | 36pcs*1W ACW LED |
| Beam angle | 25 degree(15 degree or 45 degree) |
| Control signal | DMX512 |
| Control mode | Stand alone/Master Slave |
| Max Power Consumption | 60W |
| Protection rate | IP65, IP44 Optional |
| Voltage input | AC 85-240V (50-60HZ) |
| Voltage output | 15VDC |
| Lifetime | about 50, 000-100.000 hours |
| DMX channel | 3CH\5CH\9CH\13CH\14CH |
| Weight | 4KG |
| Size | 1034*78*78mm |
| Certification | CE/RoHs/UL/CQC |
| Operate temperature | -20~+45℃ |
| Insulating Resistance | >2MΩ |
| Dielectric Strength | 1.5KV |
| Light output | 3360 Lumens |
