Brief description:
1.250W rgbw LED
2.5606 lumens output
3.Outer GOBO version, could easy replace Gobo
4.Hand zooming on construction site
Size and Weight:731*313*513mm/13.5KG
InquiryVoltage input | AC100-264V, 47-63HZ PF>0.9 |
Rated Power | 280W(262W@25℃ Peak output) |
Luminaire Efficiency | >0.7, Light Efficacy >21.4lm/W |
Optical Technology | Linear Image, plug-in GOBO plate,customized multi color GOBO |
LED Lumens | 250W Quad-RGBW LED, total 5606 Lumens |
Color | R=625nm,G=525nm, B=465nm, W=7500K, Ra>80,R9>0 |
Field Angle(10%) | 18-36 Deg zoomable Barrels, 170610cd@18Deg.39660cd@36Deg |
Control signal | DMX512,32 bit ARM MCU,PWM>3KHz,Video flicker free |
Dimming Curve | Dim 4 square law dimming, smooth in low DMX Value dimming, not Jumping, no vision shock |
Control mode | Meet E1.11 - 2004 USITT DMX512-A/stand alone/master and slave, effect speed and brightness adjustable |
Chanel option | standard 1CH, could choose 3CH=Dimmer,strobe dimming curve |
Housing material | Die cast aluminum ADC12,standard Matte black, customized glossy White painting |
Safety | Class I, compatible powercon 3C*2.5mm2 VDE cable, Flame Rating V-1, Protect Rated IP20 |
Operate temperature | -20~+45℃,Lamp body peak temperature 60℃@25℃ Enviroment |
Cerficate | Product pass CE, Rohs, SMPS pass CQC or UL60950, UL8750 |
Insulated | Dielectric strength 1.5KV, Impedance strength > 2MΩ |
Size | L*W*H=731*313*513mm |
N.W. | 13.5KG(with Barel, not with T stand) |
